PART 9: EIGRP Graceful Shutdown

Enhanced Interior Gateway Routing Protocol

EIGRP includes a graceful shutdown mechanism that allows routers to explicitly signal their intention to leave the network. This feature significantly improves convergence time compared to waiting for hold timers to expire.

Purpose of Graceful Shutdown

The primary benefit of graceful shutdown is faster network convergence. When a router needs to be removed from the EIGRP topology, graceful shutdown allows neighboring routers to:

1. Immediately recognize the departure of the router

2. Avoid waiting for the hold timer to expire (typically 15 seconds on LAN interfaces)

3. Begin route recalculation processes immediately

4. Find alternate paths without unnecessary delay


How Graceful Shutdown Works

When graceful shutdown is triggered, the router sends a special Hello packet to all neighbors with a distinctive signature:

• All K-values in this Hello packet are set to 255 (normally impossible configuration)

• Neighbors recognize this special packet as a termination signal

• Neighbors immediately mark the adjacency as down

• Syslog messages indicate "PEER-TERMINATION received"

• Route recalculation begins immediately


Triggering Graceful Shutdown

Graceful shutdown can be initiated in several ways:

1. Using the Shutdown Command

# Numbered mode
Router(config-router)# shutdown

# Named mode
Router(config-router-af)# shutdown

2. Removing Network Statements

Removing a network statement that enabled EIGRP on an interface will trigger graceful shutdown for neighbors on that interface.

3. Clearing the EIGRP Process

Router# clear ip eigrp neighbors

This command sends the graceful shutdown signal before resetting the EIGRP process.

Identifying Graceful Shutdown Events

When graceful shutdown occurs, you'll see a distinctive syslog message:

*Jul 5 18:27:00.289: %DUAL-5-NBRCHANGE: EIGRP-IPv4 1: Neighbor 192.168.15.5 (Ethernet0/0) is down: Interface PEER-TERMINATION received

The key indicator is "Interface PEER-TERMINATION received" which confirms the neighbor properly signaled its departure.

Important Limitations

Not all EIGRP termination events use graceful shutdown:

• Shutting down an interface does not trigger graceful shutdown

• Power loss or device failure cannot trigger graceful shutdown

• Only controlled, software-initiated events use this mechanism


Practical Application

Graceful shutdown is particularly valuable during:

• Planned maintenance windows

• EIGRP process reconfiguration

• Controlled network topology changes

• Software upgrades requiring routing process restart

In these scenarios, the feature minimizes packet loss by allowing faster convergence than would occur from hold timer expiration.

---
